1.Sollicitatie(LiYY-kabel):
Voor signaal- en besturingskabels in de elektronica van computersystemen, elektronische besturingsapparatuur, kantoormachines of procesbesturingseenheden.
 |
 |
 |
 |
2.Normen(LiYY-kabel):
IEC 60332
3.Kabelconstructie(LiYY-kabel):
|
|
4.Parameter (LiYY-kabel):
|
Sectiegebied |
Nominale spanning |
Testspanning |
Min. Isolatie |
|
0.14-0.34 mm2 |
250/250V |
1200V |
200 |
|
0.5-0.75 mm2 |
300V |
2000V |
200 |
|
1.0-1.5 mm2 |
300/500V |
3000V |
200 |
|
Aantal |
Geleider |
Isolatie |
Schede |
Algemeen |
Max. DCR |
|
0.14 mm2 |
|||||
|
2 |
12/0.12 |
0.35 |
0.4 |
3.2 |
148 |
|
3 |
12/0.12 |
0.35 |
0.4 |
3.5 |
148 |
|
4 |
12/0.12 |
0.35 |
0.5 |
3.9 |
148 |
|
5 |
12/0.12 |
0.35 |
0.5 |
4.3 |
148 |
|
7 |
12/0.12 |
0.35 |
0.6 |
4.8 |
148 |
|
8 |
12/0.12 |
0.35 |
0.6 |
5.2 |
148 |
|
10 |
12/0.12 |
0.35 |
0.7 |
6.2 |
148 |
|
12 |
12/0.12 |
0.35 |
0.7 |
6.5 |
148 |
|
14 |
12/0.12 |
0.35 |
0.7 |
6.7 |
148 |
|
0.25 mm2 |
|||||
|
2 |
14/0.15 |
0.4 |
0.4 |
3.6 |
79.9 |
|
3 |
14/0.15 |
0.4 |
0.4 |
3.9 |
79.9 |
|
4 |
14/0.15 |
0.4 |
0.5 |
4.4 |
79.9 |
|
5 |
14/0.15 |
0.4 |
0.5 |
4.8 |
79.9 |
|
7 |
14/0.15 |
0.4 |
0.6 |
5.4 |
79.9 |
|
8 |
14/0.15 |
0.4 |
0.6 |
5.8 |
79.9 |
|
10 |
14/0.15 |
0.4 |
0.7 |
7 |
79.9 |
|
12 |
14/0.15 |
0.4 |
0.7 |
7.3 |
79.9 |
|
14 |
14/0.15 |
0.4 |
0.7 |
7.6 |
79.9 |
|
0.34 mm2 |
|||||
|
2 |
20/0.15 |
0.4 |
0.5 |
4.2 |
57 |
|
3 |
20/0.15 |
0.4 |
0.5 |
4.5 |
57 |
|
4 |
20/0.15 |
0.4 |
0.6 |
5.1 |
57 |
|
5 |
20/0.15 |
0.4 |
0.6 |
5.5 |
57 |
|
7 |
20/0.15 |
0.4 |
0.7 |
6.2 |
57 |
|
8 |
20/0.15 |
0.4 |
0.7 |
6.7 |
57 |
|
10 |
20/0.15 |
0.4 |
0.8 |
8 |
57 |
|
12 |
20/0.15 |
0.4 |
0.8 |
8.3 |
57 |
|
14 |
20/0.15 |
0.4 |
0.8 |
8.7 |
57 |
|
0.5mm2 |
|||||
|
2 |
16/0.20 |
0.45 |
0.6 |
4.8 |
39 |
|
3 |
16/0.20 |
0.45 |
0.6 |
5.2 |
39 |
|
4 |
16/0.20 |
0.45 |
0.6 |
5.6 |
39 |
|
5 |
16/0.20 |
0.45 |
0.6 |
6.1 |
39 |
|
7 |
16/0.20 |
0.45 |
0.6 |
6.6 |
39 |
|
8 |
16/0.20 |
0.45 |
0.7 |
7.4 |
39 |
|
10 |
16/0.20 |
0.45 |
0.7 |
8.6 |
39 |
|
12 |
16/0.20 |
0.45 |
0.8 |
9.2 |
39 |
|
14 |
16/0.20 |
0.45 |
0.9 |
9.8 |
39 |
|
0.75 mm2 |
|||||
|
2 |
24/0.20 |
0.5 |
0.6 |
5.4 |
26 |
|
3 |
24/0.20 |
0.5 |
0.6 |
5.8 |
26 |
|
4 |
24/0.20 |
0.5 |
0.6 |
6.3 |
26 |
|
5 |
24/0.20 |
0.5 |
0.7 |
7.1 |
26 |
|
7 |
24/0.20 |
0.5 |
0.7 |
7.7 |
26 |
|
8 |
24/0.20 |
0.5 |
0.8 |
8.6 |
26 |
|
10 |
24/0.20 |
0.5 |
0.8 |
10 |
26 |
|
12 |
24/0.20 |
0.5 |
0.9 |
10.6 |
26 |
|
14 |
24/0.20 |
0.5 |
1 |
11.3 |
26 |
|
1.0MM2 |
|||||
|
2 |
32/0.20 |
0.6 |
0.6 |
6.2 |
19.5 |
|
3 |
32/0.20 |
0.6 |
0.6 |
6.7 |
19.5 |
|
4 |
32/0.20 |
0.6 |
0.7 |
7.5 |
19.5 |
|
5 |
32/0.20 |
0.6 |
0.7 |
8.2 |
19.5 |
|
7 |
32/0.20 |
0.6 |
0.8 |
9.1 |
19.5 |
|
1,5 mm2 |
|||||
|
2 |
30/0.25 |
0.6 |
0.6 |
6.8 |
13.3 |
|
3 |
30/0.25 |
0.6 |
0.7 |
7.6 |
13.3 |
|
4 |
30/0.25 |
0.6 |
0.7 |
8.2 |
13.3 |
|
5 |
30/0.25 |
0.6 |
0.8 |
9.2 |
13.3 |
|
7 |
30/0.25 |
0.6 |
0.9 |
10.5 |
13.3 |
5. Productievoortgang
6. Certificaten:
 |
 |
7. Verpakking:
-Stalen houten trommel (begassing)
Kabellengte in elke trommel: 1000 m/2000 m of volgens de werkelijke kabellengtevereisten.
-Trommelgrootte:
Volgens kabellengte en containergrootte
Om u een nauwkeurige prijs te kunnen geven, verzoeken wij u ons de benodigde hoeveelheid kabellengte te vertellen. Grotere hoeveelheid, meer kortingsvoordeel voor u klaar!
-Verzendhaven:
Qingdao, of andere havens volgens uw vereisten.
-Zeevracht:
De FOB/C&F/CIF-offerte is allemaal beschikbaar.
 |
 |
 |
